ADVANTAGES

  • Large screen(128×64 dot matrix LCD), showing all functions and parameters.
  • Test at any angle, even upside down.
  • Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL and three types of strength values immediately.
  • Seven impact devices are available for special application. Automatically identify the type of impact devices.
  • Large capacity memory can save 250 groups (at most 6500 single time measured value) of datas, each group include: most 26 single time measured value,average value,measure time and data, the impact direction,number of times,mater ial and hardness scale…etc., can keep over a long period of time with have hereafter browse,edit,print.
  • Upper and lower limit can be preset. It will alarm automatically when the result value exceeding the limit.
  • Battery information indicates the rest capacity of the battery and the charge status.
  • User calibration function.
  • RS232 port with the PC humanity multi-functions data proceeding software.
  • Auto power off to save energy.
  • Excellent after-sale service system for high quality products—two years’ guarantee and all life maintenance. Easy to buy and comfortable to use.

Main Application

  • Die cavity of molds
  • Bearings and other parts
  • Failure analysis of pressure vessel, steam generator and other equipment
  • Heavy work piece
  • The installed machinery and permanently assembled parts
  • Testing surface of a small hollow space
  • Material identification in the warehouse of metallic materials
  • Rapid testing in large range and multi-measuring areas for large-scale work piece

Technical Specifications

  • Measuring range:HLD(170~960)HLD
  • Measuring direction:360°
  • Hardness Scale:HL、HB、HRB、HRC、HRA、HV、HS
  • Display:dot matrix LCD,128×64 dots
  • Data memory: 250 groups max.(relative to impact times 32~1)
  • Continuous working period:about 150 hours(With backlight off, no printing)
  • Communication interface:RS232

Configuration

No. Item Quantity Remarks
Standard 1 Main Unit 1
Configuration
2 D type impact device 1 With cable
3 Standard test block 1
4 Cleaning brush (I) 1
5 Small support ring 1
6 Battery Charger 1
7 Paper for printing 1
8 Manual 1
9 Instrument case 1
10 DataPro software 1
11 Communication cable 1
Optional 12 Cleaning brush (II) 1 For use with G type
Configuration impact device
