FEATURES

HIGH ACCURACY AND RESOLUTION UP TO 0.001mm or 0.0001 inch
MEASURING ULTRA THIN SAMPLE AS LOW AS 0.15mm or 0.006 inch
DISPLAY UNITS : IMPERIAL and METRIC
AUTOMATIC SELF CALIBRATION
COUPLANT INDICATOR
AUTOMATIC POWER OFF DEVICE
HIGH-LOW LIMIT ALARM
LCD BRIGHTNESS ADJUST
LOW BATTERY INDICTOR

TECHNICAL SPECIFICATIONS



Measuring Range (for Interface-Echo Mode: 1.50mm – 20.0mm
steel)
(I-E or Standard (0.059in – 0.787 in)
Mode)
Echo-Echo Mode: 0.15mm – 10.0mm
(E-E or High (0.006in – 0.394in)
Precision Mode)
Measuring Accuracy ±0.005mm or 0.0002 inch (if thickness < 3mm)
TMTeck Instrument Co., Ltd. Tel:86-10-89444420Fax: 86-10-89445181



www.tmteck-ndt.com.cn
±0.05mm or 0.002 inch (if thickness < 20mm)
Display Resolution mm : 0.1 / 0.01 / 0.001
inch : 0.01 / 0.001 / 0.0001
Sound Velocity Range 1000 to 9999 m/sec (0.0394 – 0.3936 inch/ms)
Measuring Refresh 4Hz in normal mode, up to 25Hz
Frequency
Memory Capacity 500 test values
Multiple Calibrations One point or Two Point
Display LCD 42×57mm LCD size with EI backlight and
adjustable contrast, font size up to 13.75mm (0.54
inch)
Power Source 2 pcs. 1.5v AA size batteries
Continuous working About 200 hours (with backlight off)
period
Power off Auto power off if idle for 4 minutes
Operating Temperature -10 °C to +50 °C
Unit Size 2.9 W x 5.9 H x 1.26 D inches (73 W x 149 H x 32
D mm).
Weight 200g



STANDARD DELIVERY

  1. Main Processor with Calibration block (4.00 mm)
  1. Precision Probe (D11R) with Replaceable Delay Tip
  1. Coupling Paste
  1. Operation Manual
  1. Consumer-Type 2 AA Type Alkaline Battery (3 Volt)
  1. Carrying Case
