FEATURES
- Capable of performing measurements on a wide range of material, including metals, plastic, ceramics, composites, epoxies, glass and other ultrasonic wave well-conductive materials.
- Transducer models are available for special application, including for coarse grain material and high temperature applications.
- Probe-Zero function, Sound-Veloctiy-Calibration function.
- Two-Point Calibration function.
- Coupling status Indicator showing the coupling status.
- Battery information indicates the rest capacity of the battery.AAA model battery and Ultra-low power consumption, it is can continue working 100 hours.
- Auto sleep and auto power off function to conserve battery life.
- Usb port with Protective Membrane and datapro software to process the memory data on the PC.
- Optional thermal mini-printer to print the measured data via USB port.
- Adjust gain function ,can easy to test the cast iron material,
Specifications
Display: 128×64 LCD with LED backlight.
Measuring range: 0.75mm~300.0mm (0.03inch~11.8 inch)
Sound velocity: 1000m/s~9999m/s (0.039~0.394in/µs
Display resolution:0.01mm or 0.1mm (lower than 100.0mm)
0.1mm (more than 99.99mm)
Accuracy: ±(0.5%Thickness +0.02)mm, depends on Materials and conditions
Units: Metric/Imperial unit seletable.
Lower limit for steel pipes: 5MHz probe: F20mm´3.0mm(F0.8´0.12 inch)
10MHz probe: F20mm´3.0mm(F0.6´0.08 inch)
Power Source: 2pcs 1.5V AA size, batteries.100 hours typical operating time(LED backlight off).
Communication: USB serial port
Outline Dimensions: 150mm×74mm×32mm
Weight: 238 g
Four measurements readings per second for single point measurement,
Memory for up to 5 files(up to 100 values for each file) of stored values
Configuration
| No | Item | Quantity | Note | |||||||
| 1 | Main body | 1 | ||||||||
| 2 | Transducer | 1 | Model: TM-08 | |||||||
| 3 | Couplant | 1 | ||||||||
| Standard | 4 | Instrument Case | 1 | |||||||
| Configuration | 5 | Operating Manual | 1 | |||||||
| 6 | Alkaline battery | 2 | AA size | |||||||
| 12 | DataPro Software | 1 | ||||||||
| 13 | Communication Cable | 1 | ||||||||
| 7 | Transducer: TM-12 | |||||||||
| Optional | 8 | Transducer: TM-06 | Appendix A | |||||||
| 9 | Transducer: HT5 | |||||||||
| Configuration | ||||||||||
| 10 | Mini thermal printer | 1 | ||||||||
| 11 | Print cable | 1 | ||||||||
| Probe optional for ultrasonic thickness gauge | ||||||||||
| Model | Freq. | Diam. | Measuring range | Lower limit | Description | |||||
| MHz | Min. | |||||||||
| 3.0mm-300.0mm | For thick, highly | |||||||||
| TM-12 | 2 | 14 | 20 | attenuating, or highly | ||||||
| (in steel) | ||||||||||
| scattering materials | ||||||||||
| TM-08 | 5 | 8 | 1.2mm-230.0mm | ￠20mm×3.0mm | Normal measurement | |||||
| (in steel) | ||||||||||
| TM-08/90 | 5 | 8 | 1.2mm-230.0mm | ￠20mm×3.0mm | Normal measurement | |||||
| (in steel) | ||||||||||
| 0.75mm-80.0mm | For thin pipe or small | |||||||||
| TM-06 | 7 | 6 | ￠15mm×2.0mm | curvature pipe wall | ||||||
| (in steel) | ||||||||||
| thickness measurement | ||||||||||
| HT-5 | 5 | 13 | 3mm-200mm (in | 30 | For high temperature | |||||
| steel) | measurement (up to 300℃) | |||||||||
| HT5-2 | 5 | 13 | 3mm-200mm (in steel) | 30 | For high temperature measurement (up to 550℃) | |||||
