FEATURES

AUTOMATIC SELF CALIBRATION
COUPLANT INDICATOR
AUTOMATIC POWER OFF DEVICE
HIGH-LOW LIMIT ALARM
LCD BRIGHTNESS ADJUST
THROUGH COATING CAPABILITY
LOW BATTERY INDICTOR

TECHNICAL SPECIFICATIONS

TM230D TM250D
MEASURING STANDARD 0.8mm – 250mm Depending of the
RANGE probes
(STEEL)
THROUGH 3mm – 18mm Depnding of the probes
COATING
DISPLAY RESOLUTION 0.1mm or 0.1mm/0.01mm or
0.01inch
0.01inch/0.001inch
TOLERANCE +/- 0.1mm in +/- 0.025mm in steel
steel
VELOCITY RANGE 1000-9999 m/s (0.0393-0.3936 inch/μs)
DISPLAY TYPE 4 digital LCD with advanced backlight
MEMORY 500 Test Values
POWER 2 pcs. 1.5v AA Batteries
OUTSIDE DIMENSION 149mm×73mm×32mm
WEIGHT 160g

STANDARD DELIVERY

  1. MAIN UNIT WITH THOUGH COATING MODE
  2. STANDARD PROBE PT-08
  3. COUPLANT BOTTLE
  4. TWO AA SIZE 1.5V BATTERIES
  5. OPERATION MANUAL
  6. CARRYING CASE
